Specifications:

Mode: DMR (Digital Mobile Radio Standard) and Analogue

TDMA – Tier II Digital

DMO Dual Slot Trunk (pseudo/virtual/auto slot select)

Dual Slot Specific (DCDM) plus RMO

Analogue Integration including CTCSS/DCS (ideal for migrating between analogue and digital systems)

Approved for LMRS and CBRS use

Frequency Range:  400 – 480Mhz

64 Channels, 4 zones, 16CH per zone

Channel spacing: 12.5Khz

Battery Working Time (avg 5/5/90):  16hrs Digital mode

Power Output: 5W/1W

Modulation: 4FSK –  7K60FXD   7K60FXE   10K1F3E & 16K0F3E (70cm)

Sensitivity: 5% BER<=0.25uV – digital  / <=0.22uV (12dB SINAD) – analogue

High Capacity Rechargeable Li-ion Battery

Allows mixed modes in the same zone

Programmable side button functions

Battery Save Option.

Encryption available in digital trunk mode if required, for maximum security

Group Alert Alarm option in digital mode and Lone Worker Function.

Voice Prompt/Guide

Vocoder:  AMBE+2

Full Length Aluminium Alloy Chassis

Certified IP67 waterproof and dust proof

Simple use and rugged design

Weights 225g with battery and antenna

Housing size:  97H x 56W x 38D mm

Radio ID information can be received by the FDP DMR800.

The FDP Pro DMR64 is also capable of analogue wide/narrowband use on the Amateur ‘Ham’ Radio 70cm band, by licensed operators

Best value IP67 waterproof Approved Digital Radio available in the Australian Market – compatible with other compliant DMR systems.

Most accessories interchangeable with the FDP Pro (excludes wired earpiece mikes in digital mode).

Radio kit comes with: Radio, Battery, Antenna, Charging Cradle, Wall Adapter for Charging Cradle, and Belt Clip.

is one of the most feature packed IP67 certified waterproof & dustproof handheld radio available for both the Citizen Band Radio Service and Land Mobile Radio Service, being AS/NZS Approved to both. Allows up to 128 Channels for the LMRS covering 430 – 500 Mhz. This compact, stylish and rugged transceiver represents superb value when you consider the list of extensive features that include Multi Battery Save, VOX, Frequency Receive Mode, Keypad access CTCSS/DCS, Voice Prompt Guide, PTT ID, Scrambler, Alpha Tagging and so much more. The special ‘Function Button Disable’ feature can also lock the radio to being Software Defined* only, making the radio very simple to use if required.

Features:

Channels 1 – 80 UHF 5W CB

16 Duplex Channels & Alpha Tagging for Repeaters

Hi/Lo Power Select levels (5W/1W)

Adjustable Squelch levels: 0-9

High Capacity Rechargeable Li-ion Battery

Scrambler (up to 8 levels)

Keypad Lock/Unlock

VOX

Channel Scan (3 modes)

Frequency Receive Mode

Built in FM Radio Receiver

CTCSS/DCS access via keypad

Voice Prompt/Guide (handy for the vision impaired or when you cant see the screen)

Group Alert Alarm**

Full Length Aluminium Alloy Chassis

Housing size:  97H x 56W x 38D mm

Dealer Programmable Features:

LMRS approved – 128 Channels between 430 – 500Mhz

Alpha Tagging of channels

Priority Channel Scan

Battery Save Feature – multi levels (5) 30hrs standby and up

DTMF/MSK ANI PTT ID

SELCALL DTMF – individual or group selective calling

Function Button Disable

Radio kit comes with: Radio, Battery, Antenna, Charging Cradle, Wall Adapter for Charging Cradle, 12V Car Lighter Adapter for Charging Cradle, Belt Clip and Manual.

*Please note that ‘Software Defined’ means that features like power, squelch, channel allocations, CTCSS/DCS, scrambler and battery save are all preset by the distributor or approved dealer with software, and can’t be changed via the keypad, making this an easy to use, powerful, no nonsense transceiver for commercial or recreational use if required.

**  The Group Alert Alarm will only activate for less than 3 seconds in any 60 second period, regardless of how many times it is press in that minute.  This is to comply to the CBRS tone timing restrictions imposed by the Standard.

Sleek, compact and light-weight design, yet still MIL-SPEC tough.  Equally at home in the restaurant, corporate office or on the work site, the FDP DMR800 Handheld with analogue integration, allows transition between analogue & digital systems, including UHF CB.

Specifications:

Mode:  DMR (Digital Mobile Radio Standard) and Analogue.

TDMA – Tier II Digital

DMO Dual Slot Trunk (pseudo/virtual/auto slot select)

Dual Slot Specific (DCDM) plus RMO

Approved for LMRS use

Approved for CB use

Frequency Range:  400 – 480Mhz

800 Channels, 50 zones, 16CH per zone

Channel spacing: 12.5Khz

Battery Working Time (avg 5/5/90):  20hrs Digital mode     14hrs Analogue   @ 1:2 battery save (default)

Power Output: 5W/1W

Modulation: 4FSK –  7K60FXD   7K60FXE   16K0F3E  &  10K1F3E

Sensitivity: 5% BER<=0.25uV – digital     0.25uV (12 SINAD) – analogue

All Call, Group Call and Private Call or text messaging with individual radio ID’s

Allows mixed modes in the same zone

Programmable side button functions.

Multiple Battery Save Options

Encryption available in digital mode if required, for maximum security

Group Alert Alarm option in digital mode

Large Colour LCD Polycarbonate Screen (super tough and scratch resistant) for more information and easier use

Voice Prompt/Guide

Vocoder:  AMBE+2 and FEC Technology

Full Length Aluminium Alloy Chassis

MIL-STD-810C/D/E/F:  Shock and Vibration

Weatherproof / rainproof / splashproof

Housing size:  108H x 57W x 32D mm

Holds up to 1024 Digital Contacts

Radio kit comes with: Radio, Battery, Antenna, Charging Cradle, Wall Adapter for Charging Cradle, and Belt Clip.

Primary sample code plugs setup available for 70CM* DMR repeaters plus talk groups, and for CB radio (will not accept .CSV or .rdt files)

Best value Approved Digital Radio available in the Australian Market – compatible with other compliant DMR systems.

*Please note that the sample 70cm ham codeplug is not a complete list of VK DMR repeaters, but more of an example of how to set the parameters, using VK4 as a guide.  Includes TG’s, 70cm common simplex channels (segment specific to band plan – digital & analogue) and includes CB channels with repeaters.
